Friday, February 27, 2015

ConfigEngine webdav-deploy-zip-file results in MissingAccessRightsException (WP 8.5)


Last night I needed to deploy some updates to the static portion of my WebSphere Portal v8.5 theme, which is something I've done many times before without issue.  The developers provided a .zip file containing the changes they'd made via WebDAV to the theme on the development server, I dropped it onto my test server, and issued the ConfigEngine.sh webdav-deploy-zip-file command with the appropriate (and correct) parameters.

Ninety seconds later, the dreaded words "BUILD FAILED" roll up my console.  Ugh.

BUILD FAILED
Oh boy, here we go again...
"Exception found when executing wsadmin" is fairly cryptic, so I went through the trace logs and found that the process was failing shortly after starting the wsadmin session with the the error "com.ibm.wps.services.webdav.MissingAccessRightsException: EJPFB0002E: Exception occurred" - this looks bad.

I double checked my parameters, validated my wkplc.properties file, checked that my admin account was not locked, and tried again.  Same error.  After double checking everything again, I decided it was time to restart the cluster.  I shut everything down, including the node agents, cleared out the typical temp folders, and brought my deployment manager back online.  Once that was good, I started up all of the node agents and checked the sync status of my cluster:  All green.  I forced a full re-sync anyway.  The re-sync went off without a problem, so I started up the portal servers and watched the logs for any signs of trouble, but there weren't any.

Since everything was still looking good, I went ahead and ran the webdav-deploy-zip-file command again... 10 minutes later, BUILD SUCCESSFUL!  Great!

In summary, if I ever see another MissingAccessRightsException: EJPFB0002E while trying to use wsadmin to deploy a static theme, my first action will be to restart the cluster and try again!

Happy Portalling!

Tuesday, May 27, 2014

Resolving Issues with IBM WebSphere Portal 8.0 Default Search Service, Crawlers, and Collections



After installing, clustering, and securing WP 8.0, the search services and collections may need to be recreated, but this process seems fragile. Multiple restarts and multiple attempts to recreate the default search service and the default Portal / WCM collections result in an array of errors that can be difficult to isolate.
Some of the error messages seen in the logs and in the UI when the Search Services are mis-configured:
  • Unable to start Portal Search Service
  • Unable to create WebScanner
  • Failed to parse CrawlerStatus xml

To completely reset the search services, I eventually had to take the following steps:
  • Delete the Default Search Service via the Portal Admin console
  1. Stop server(s)
  2. Delete all files in /usr/wps/WebSphere/wp_profile/PortalServer/CollectionsConfig
  3. Start the server(s)
  • Update Search Service Credentials
  1. Manage Search -> Search Services -> Default Search Service -> Default Search Collection
  2. Edit "Portal Content Source", "Security" tab to manually update credentials

    Note: I had a problem with my Portal Source due to incorrect protocol in the generated seedlist URI. This was causing a failure with a 401 HTTP code. To fix it I had to switch the URI from HTTPS to HTTP and restart the crawler.
  3. Edit "WCM Content Source", "Security" tab to manually update credentials
  4. Run both crawlers
  5. Win.

Snippets of the stack traces I encountered in my portal logs during this process:

PortalCollect E com.ibm.hrl.portlets.WsPse.PortalCollectionsService createWebScannerLite EJPJO0032E: Unable to create Webscanner
com.ibm.lotus.search.engine.SearchAdminException: Failed to get crawler status from persistence layer.
...
(the following line was a big clue!)
Caused by: com.ibm.lotus.search.engine.PersistenceException: Failed to parse CrawlerStatus xml.
at com.ibm.lotus.search.engine.PersistenceService.getCrawlerStatus(PersistenceService.java:313)
at com.ibm.lotus.search.engine.SearchAdminService.init(SearchAdminService.java:686)
... 47 more
Caused by: org.xml.sax.SAXParseException: Content is not allowed in trailing section.
at org.apache.xerces.parsers.DOMParser.parse(Unknown Source)
at org.apache.xerces.jaxp.DocumentBuilderImpl.parse(Unknown Source)
at com.ibm.lotus.search.engine.xml.SearchEngineInternalContentHandler.parseCrawlerStatus(SearchEngineInternalContentHandler.java:75)
at com.ibm.lotus.search.engine.PersistenceService.getCrawlerStatus(PersistenceService.java:311)
... 48 more
PortalCollect E com.ibm.hrl.portlets.WsPse.PortalCollectionsService PortalCollectionsService EJPJO0119E: Failed to initialize portal collections services.
com.ibm.hrl.portlets.WsPse.PortalWebScannerException: EJPJO0032E: Unable to create Webscanner
...
Caused by: com.ibm.lotus.search.engine.SearchAdminException: Failed to get crawler status from persistence layer.
at com.ibm.lotus.search.engine.SearchAdminService.init(SearchAdminService.java:688)
at com.ibm.lotus.search.engine.SearchEngineWebScannerLiteImp.init(SearchEngineWebScannerLiteImp.java:180)
at com.ibm.lotus.search.engine.SearchEngineWebScannerLiteImp.setProp(SearchEngineWebScannerLiteImp.java:291)
at com.ibm.hrl.portlets.WsPse.PortalCollectionsService.createWebScannerLite(PortalCollectionsService.java:3669)
... 44 more
Caused by: com.ibm.lotus.search.engine.PersistenceException: Failed to parse CrawlerStatus xml.
at com.ibm.lotus.search.engine.PersistenceService.getCrawlerStatus(PersistenceService.java:313)
at com.ibm.lotus.search.engine.SearchAdminService.init(SearchAdminService.java:686)
... 47 more
Caused by: org.xml.sax.SAXParseException: Content is not allowed in trailing section.
at org.apache.xerces.parsers.DOMParser.parse(Unknown Source)
at org.apache.xerces.jaxp.DocumentBuilderImpl.parse(Unknown Source)
at com.ibm.lotus.search.engine.xml.SearchEngineInternalContentHandler.parseCrawlerStatus(SearchEngineInternalContentHandler.java:75)
at com.ibm.lotus.search.engine.PersistenceService.getCrawlerStatus(PersistenceService.java:311)
... 48 more

Happy Portalling!

Friday, May 9, 2014

IBM Lotus Connections Media Gallery Video Playback Fails with Error #2032

In my Connections 4.0 environment, any attempt to play a video file through the embedded media player would fail with the mysterious code "Error #2032".

Error #2032 on Video Playback

Digging a little deeper with Fiddler uncovered a 404 error for a file called "textLayout_1.0.0.595.swz".  This file does not exist on my Connections server.


Apparently it is common for the Adobe Flash plugin to reach out to Adobe's website for certain supporting localization and support files, but in our environment that wasn't possible so it attempted to find the file on the internal server instead..  Why these files weren't included with Connections is a good question that I never did get an answer to.

I was able to locate the missing file (textLayout_1.0.0.595.swz) on the Adobe web site at this URL: http://fpdownload.adobe.com/pub/swz/tlf/1.0.0.595/textLayout_1.0.0.595.swz

Once I had the file, I was able to follow the procedure documented in the following Connections Customization article to customize my Connections installation with the missing file:  http://infolib.lotus.com/resources/connections/4.0/doc/en_us/ic4_p4.html#t_admin_common_customize_main

Then I tried again... and the problem persisted.  Another fiddler trace revealed that the 404 had moved on to a different .swz file, though, so I repeated the process again for osmf_flex.4.0.0.13495.swz, then again for another .swz... and so on until I had added each of the following to my Connections installation:

  • framework_4.0.0.14159.swz
  • osmf_flex.4.0.0.13495.swz
  • rpc_4.0.0.14159.swz
  • sparkskins_4.0.0.14159.swz
  • spark_4.0.0.14159.swz
  • textLayout_1.0.0.595.swz

Once all of these .swz files were hosted locally within my Connections installation, the Media Gallery started playing video normally!

Happy Portalling!

Note:  Your particular Connections Media Gallery Video Player (sn_media_video_player) may require different versions of these .swz files, but a little searching on the Adobe site should help you find the ones you need.



Wednesday, February 12, 2014

Installing OmniFind 9.1 to AIX 7.1 - Workaround for IBM XL C++ for AIX, V10.1.02 Error


When attempting to install Omnifind 9.1 to an AIX 7.1 server, I encountered an error stating: "Required AIX Library is Missing" with details telling me that "xlC.aix.rte version must be 10.1.0.1 or later."  I check the AIX machine and found that my xlC.aix.rte  version was actually 12.1.0.0... should be good to go, right?  Not so much!


Digging a little deeper, I found that a script named "getxlcversion61.sh" was being placed in my temporary folder during the installation process.  This script ran and generated a text file containing the xlc version, but the text file was empty and the version check failed.  Turns out that there's a bug in this script causing the problem, and here's how you get around it:

  1. Locate or define the temp directory for your installation.  You may define it by setting the IATEMPDIR environment variable to whatever works best for you:
    1. export IATEMPDIR=/usr/omnifind/tmp
  2. Start Omnifind Installer:
    1. cd <installer dir>/Main
    2. ./install.bin
    3. Choose Language & click “OK”
  3. STOP! DO NOT ACCEPT LICENSE AGREEMENT!
  4. Move to the OmniFind 9.1 temp directory on your system and find the getxlcversion61.sh file:
    1. find . -name "getxlcversion61.sh"
    2. This file is only available while the installer is running.  If you quit the install, it cleans up after itself and removes this file.
    3. This file is stored in a temporary, numbered directory within your temp folder.
  5. Update the following line to remove "C/":
    1. VERSION=`lslpp -lq xlC.aix61.rte 2>/dev/null | grep "XL C/C++ Runtime" | cut -f16 -d" "` [BAD!]
    2. VERSION=`lslpp -lq xlC.aix61.rte 2>/dev/null | grep "XL C++ Runtime" | cut -f16 -d" "` [GOOD!]
  6. Save and close getxlcversion61.sh.
  7. Accept the license agreement.
  8. Ignore the “unsupported OS” warning if installing to AIX 7.1.
  9. Continue with the installation... and good luck!
Happy Portalling!

Thursday, December 12, 2013

Develop WebSphere Portal 8 Portlets without RAD


My buddy Gabriel posted a great article about creating portlets for IBM WebSphere Portal 8 without the need for RAD (Rational Application Developer) by creating some simple, custom actions in the Eclipse IDE.  Great stuff, and I can't wait to try it out!

See the article here: http://theoreticaltechstuff.blogspot.com/2013/12/creating-portlets-without-rad-ibm.html?showComment=1386859313424#c3336981388793430830

Monday, March 18, 2013

IBM Launchpad Will Not Start: Unable to find supported browser



I encountered this issue when attempting to start the launchpad to start an IBM WebSphere Portal 8 installation via the IBM installation manager - took me a while to sort out, so hopefully this write-up will save someone else some time!

When trying to fire up the IBM Launchpad application via the Setup.sh command on a system where Mozilla Firefox 17+ is configured as the default browser, you may receive an error message in your browser:

Unable to find supported browser
An error occurred while starting the launchpad. This error typically occurs when the launchpad is unable to find a supported browser. Check your product's documentation for a list of supported browsers.
NOTE: This file is a place holder for product specific instructions about how to recover from this error.
You should describe the location of installation programs on the product CD so the user can run them directly without starting launchpad if necessary.
Procedure for correcting the error that is preventing the launchpad from displaying
==============================================================
The launchpad supports the following browsers:
o Mozilla
o Firefox
o Internet Explorer (Microsoft Windows platforms only)
o SeaMonkey

With a little digging, you'll discover that the whichBrowser variable in launchpad\browser.sh script (called by Setup.sh) is actually being set correctly, and that your browser is being opened with the following, valid command:
/usr/bin/firefox -P Profile_2883 -profile /tmp/IBM_LaunchPad_2883/Profile_2883 file:///media/sf_websphere_media/media_80/wp_package/Setup/launchpad/Mozilla.html
This will immediately redirect you to file:///media/sf_websphere_media/media_80/wp_package/Setup/launchpad/en/noBrowser.html - it may not even be apparent that a redirection occurs, which can be frustrating.

What's happening here is that the javascript file "Mozilla.js" (called from "Mozilla.html") is attempting to make a netscape.security.PrivilegeManager.enablePrivilege call, which is no longer supported by Firefox.  This throws a javascript error, which triggers the redirect.
Mozilla.js Line 43: netscape.security.PrivilegeManager.enablePrivilege("UniversalXPConnect");
Support for enablePrivilege has been removed in Firefox (Bug 546848), so it is no longer possible to get special elevated privileges by using this method.
For details about the change to Firefox, the following support note: http://support.mozilla.org/en-US/questions/944433


To get around this problem, I installed an older version of Firefox (10.2).  Once I did this, everything worked great!  You can find older versions of Firefox here:  https://ftp.mozilla.org/pub/mozilla.org/firefox/releases/

Happy Portalling!

Wednesday, March 13, 2013

CentOS 6 Minimal Desktop Install Tip

I've had to do this a few times, and I always forget the commands - this time I stumbled upon jbmurphy's blog and an old post that already had the information I needed:


yum groupinstall basic-desktop desktop-platform x11 fonts


http://www.jbmurphy.com/2011/12/01/how-to-add-gnome-to-centos-6-minimal-install/

Thanks JBM :)
